Diffusion Models: From Noise to Image — and Into Midjourney v6 — Atlas

The Unifying Object

∇_x log p(x)

Every architecture surveyed — U-Net, DiT, MMDiT, FLUX — is a different box for computing this single object: the score function, the gradient of the log data density. Forward diffusion destroys information by following a noise schedule; reverse diffusion reconstructs by following the score back toward data. ^[1] ^[2]

Every training objective — ε-prediction, x₀-prediction, v-prediction, rectified flow — is a reparametrisation of the same score. ^[EDM] When you dial Midjourney's --stylize up, you are amplifying the conditional score gap relative to the unconditional one. The craft is craft; the substrate is differential geometry.

ε̂ = ε(x,∅) + w·(ε(x,c) − ε(x,∅))

Classifier-Free Guidance

The formula behind every guidance_scale and --stylize parameter. w amplifies the conditional-vs-unconditional gap, steering the denoising trajectory in latent space. [EDM, Karras 2022]

The Territory — Seven Regions

REGION 01

Forward Diffusion and Noise Schedules

How the forward process works mathematically, and how the choice of noise schedule — linear, cosine, EDM σ, or Laplace — shapes training quality, resolution behaviour, and what not to get wrong.

survey 16 citations 6 min

REGION 02

Reverse Denoising: Architectures and the Score Network

How the denoiser that drives reverse diffusion is really a score network, and how its backbone evolved from U-Net to the transformers behind FLUX, SD3 and Sora.

expedition 52 citations 9 min

REGION 03

Text Conditioning via CLIP (and Beyond)

How CLIP's shared text/image embedding space powers diffusion model conditioning — and why modern models stack T5-XXL, dual CLIPs, and even full LLMs on top.

survey 20 citations 6 min

REGION 04

Why Hands Broke — and What Fixed It

A technical post-mortem: sparse training data, CLIP counting blindness, VAE resolution limits, U-Net locality, and mode-interpolation — plus the layered fixes that pushed success rates from ~30% to ~90% by 2025.

survey 21 citations 7 min

REGION 05

Midjourney v6 Prompt Craft

How to prompt Midjourney v6: drop the v5 keyword soup, write natural-language scenes, and use weights, references and parameters deliberately.

expedition 40 citations 8 min

REGION 06

Latent Space and VAE

VAEs encode data as probability distributions in latent space, enabling smooth interpolation and generative capabilities beyond standard autoencoders.

recon 5 citations 2 min

REGION 07

ControlNet and Structural Conditioning

ControlNet adds spatial control to image generation by training a parallel network branch to inject structural guidance without disrupting the base model.

recon 4 citations 2 min

Architecture Evolution — 2020 → 2024

2020

U-Net DDPM

Convolutional backbone; local context; skip connections

2021

ADM

Beats GANs; multi-head attention at coarser resolutions

2022

LDM / SD

Latent space + cross-attention; text conditioning

2023

DiT

Full transformer on patches; monotonic Gflops→FID scaling

2024

MMDiT / SD3

Joint text-image attention streams; rectified flow

2024

FLUX.1

12B MMDiT; correct fingers without anatomical training data

Five Field Notes from the Expedition

01

Architecture and anatomy are causally linked

U-Net's convolutional locality meant fingers were processed without global palm context — the network learned fingers as local textures, not as a kinematically constrained structure. DiT and MMDiT replace this with full-sequence self-attention: every finger token attends to every palm token in every layer. [DiT] FLUX.1's 12B-parameter MMDiT achieved "correct finger count in the vast majority of generations" [Ikomia] not from anatomical training data, but because global attention enforces global consistency as an architectural side-effect. The scaling law DiT demonstrated — more compute → lower FID monotonically — is the same reason FLUX outperforms SDXL on anatomy at matched prompt complexity.

02

The text encoder stack is the hidden variable behind prompt strategy

CLIP's 77-token hard limit and visual-contrastive training bias made keyword-front-loading rational in SD 1.x: token 78 onward was invisible, so packing the most important terms early was load-bearing engineering, not stylistic preference. [CLIP] Imagen's demonstration that a frozen T5-XXL outperforms CLIP on compositional prompts [Imagen] — and SD3/FLUX's stacking of dual CLIPs with T5 — is what legitimises Midjourney v6's "write a natural scene description" instruction. By 2026, HiDream-I1 uses a full Llama-3.1-8B encoder — prompt writing and LLM prompting converge completely.

03

Resolution and the VAE interact in ways the surface-level pipeline hides

The VAE's 8× spatial compression means a full-frame hand at 512px collapses to 5–8 latent pixels per finger — the decoder is asked to reconstruct detail it never saw encoded. [MakeUseOf] SDXL's move to 1024px native resolution tripled the effective latent resolution for fine anatomy. ControlNet's depth-map injection acts as a structural bypass: it supplies the spatial constraints the latent bottleneck loses, explicitly conditioning the score network on 3D structure rather than asking it to infer depth from pixel patterns alone.

04

The noise schedule's effect on practitioners is underappreciated

The EDM finding that zero terminal SNR must be enforced [Lin 2023] is directly observable in generation: models trained with the common cosine schedule produce slightly hazy darks and cannot generate pure-black backgrounds. Every sampler tuning — DDIM vs DPM-Solver vs Euler, step counts, sigma schedule — changes which part of the SNR curve gets the most compute. The practitioner proxy: when a model refuses high-contrast results, non-zero terminal SNR is leaking into inference.

05

Open question: does rectified flow change prompt-engineering intuitions?

FLUX and SD3 use rectified flow — learning straight transport paths rather than curved SDE trajectories. [Liu 2022] Empirically this makes fewer steps viable, but whether it changes which prompt tokens govern which spatial regions in cross-attention, and therefore whether front-loading rules still apply, is not yet settled in the literature. The shift in transport geometry may have entirely different implications for prompt token weighting than the DDPM-style score matching that the existing craft guidance was built on.

Midjourney v6 Parameter Deck

--stylize / --s

0 – 1000 · default 100

Amplifies the conditional score gap (CFG-equivalent). High values give Midjourney creative latitude and may stray from the prompt; 0–50 for strict literal output.

--chaos / --c

0 – 100 · default 0

Increases variance across the four-image grid. High values mean images can be quite different and may not stick closely to the prompt.

--weird / --w

0 – 3000 · default 0

Adds experimental, unconventional qualities. Experimental feature — not fully compatible with seeds. Use sparingly.

--style raw

toggle · default off

Disables Midjourney's auto-styling. More literal, photo-like results. Recommended for in-image text generation with quoted text.

--no

= X :: -0.5 weight

Negative prompt shorthand. Equivalent to a −0.5 multi-prompt weight. Total weights must remain positive or it errors.

--seed

0 – 4,294,967,295 · random

Sets starting noise for reproducibility. Turbo mode breaks reliable seed locking — avoid combining them.

The v6 Paradigm Shift

Drop the keyword soup. v5's front-loaded token strategy was load-bearing engineering for CLIP's 77-token limit and visual-contrastive bias. v6's T5-based conditioning understands grammar, syntax, and spatial relations. Write a natural-language scene description as you would brief a photographer: subject → medium → lighting → colour → composition → mood → parameters. Strip quality tokens (8k, photorealistic, award-winning) entirely — v6 penalises vague filler and rewards explicit scene description. ^{[official docs]}
